AQUALUX

Durable & High performance

aqualux-led-emergency-lighting-header-image
  • Waterproof enclosures up to IP65
  • Attractive aluminum modular enclosure with IK10
  • Frost resistance versions for low temperature environments
  • Updated version with improved LED performance
  • Easy to install & renovate existing fluorescent tube installations
  • Supervision and anticipated maintenance with Naveo®Pro and DALI versions
  • Ni-MH battery technology

More info Button Red

The robust design of the Aqualux makes the range suitable for high impact applications, such as sport complexes, swimming pools, parking garages and other outdoor settings. Made of impact-resistant (IK10), scratch-resistant polycarbonate and also water-resistant (IP65), this rugged powerhouse challenges the most demanding environments.

The latest upgrade adds flexibility to the product covering both escape route signage and lighting with the same version. This simplifies the required planning before the installation. The upgrade to Ni-MH battery technology reduces the environmental impact. The range is available in all electrical versions and using the wide range of accessories you can cover all mounting application. You can also select between two useful options: a light/dark sensor or a frost-resistant version (down to -25 °C).

Existing Aqualux installations with fluorescent tubes can be easily upgraded with an LED renovation kit, while re-using the existing mounting base. Since escape route signalisation lights up continuously the Aqualux LED provides you benefits from low energy consumption, less maintenance and a long LED life.

With the flexible range covering both the wall and ceiling applications, the new light optics provides a superb lighting performance offering even pictogram illumination and good spacing performance.

The products

Every product code available in the Aqualux range offers the double functionality !
Aqualux Lighting wave 2
Aqualux
Lighting
Aqualux signage image_A
Aqualux
Signage

New products

Order Code Description Monitoring type Power supply type  Illuminance Data sheet Instruction sheet
7331956/44 XTE9150S-M3/ST FR Automatic Self test Self Contained 106 lm  ABBpictogram_download_document_292x195 ABBpictogram_download_document_292x195
7331856/44 XTE9150S-M3/ST LS Automatic Self test Self Contained
106 lm  ABBpictogram_download_document_292x195 ABBpictogram_download_document_292x195
7331056/44 XTE9150S-M3/ST Automatic Self test Self Contained
106 lm  ABBpictogram_download_document_292x195  ABBpictogram_download_document_292x195
7341856/44 XTE9150S-M3/COM LS
Naveo®Pro Wired Self Contained 106 lm  ABBpictogram_download_document_292x195  ABBpictogram_download_document_292x195
7341056/44
XTE9150S-M3/COM
Naveo®Pro Wired Self Contained 106 lm  ABBpictogram_download_document_292x195  ABBpictogram_download_document_292x195
7341956/44
XTE9150S-M3/COM FR
Naveo®Pro Wired Self Contained 106 lm  ABBpictogram_download_document_292x195  ABBpictogram_download_document_292x195
7341056/44BT
XTE9150S-M3/BT
Naveo®Pro Wireless Self Contained 106 lm  ABBpictogram_download_document_292x195 ABBpictogram_download_document_292x195
7341856/44BT XTE9150S-M3/BT LS Naveo®Pro Wireless Self Contained 106 lm  ABBpictogram_download_document_292x195  ABBpictogram_download_document_292x195
7341956/44BT
XTE9150S-M3/BT FR Naveo®Pro Wireless Self Contained 106 lm  ABBpictogram_download_document_292x195  ABBpictogram_download_document_292x195
7339056/44 XTE9150S-M3/DALI DALI Self Contained 106 lm  ABBpictogram_download_document_292x195 ABBpictogram_download_document_292x195
7339956/44
XTE9150S-M3/DALI FR
DALI Self Contained 106 lm  ABBpictogram_download_document_292x195 ABBpictogram_download_document_292x195
7339856/44
XTE9150S-M3/DALI LS
DALI Self Contained 106 lm  ABBpictogram_download_document_292x195 ABBpictogram_download_document_292x195
7000057/44
XTE9150S-230/LTC
EMEX Test CPS 321 lm  ABBpictogram_download_document_292x195 ABBpictogram_download_document_292x195
7000056/44 XTE9150S-230
  CPS 321 lm  ABBpictogram_download_document_292x195 ABBpictogram_download_document_292x195
7000956/44
XTE9150S-230 FR   CPS 321 lm  ABBpictogram_download_document_292x195 ABBpictogram_download_document_292x195
7000957/44
XTE9150S-230/LTC FR
  CPS 321 lm  ABBpictogram_download_document_292x195 ABBpictogram_download_document_292x195

Accessories

 Order code  Description  Accessory Type
 OW/BWM  WALL BRACKET END CANTILVR AQL  Wall Mount End Cantilever Bracket
 OW/DSC  DIFFUSER DS BLANK  Blank double sided diffuser
 OW/BWA  WALL BRACKET ANGLE-MOUNT AQL  Wall mount bracket
 OW/BCR  RECESS BEZEL KIT  Recessing kit
 OW/BCM  CEILING BRACKET V-MOUNT AQL  Ceiling bracket, vertical mount
 XEN2W  ISO PICT AQL ARR DOWN  Pictogram (Back-Lit)
 XEN3W  ISO PICT AQL ARR LEFT  Pictogram (Back-Lit)
 XEN5W  ISO PICT AQL ARR UP  Pictogram (Back-Lit)
 XEN6W  ISO PICT AQL ARR RIGHT  Pictogram (Back-Lit)
 RSEN2W  ISO STICK AQL ARR DN  Pictogram (Edge-Lit)
 RSEN3W  ISO STICK AQL ARR LT  Pictogram (Edge-Lit)
 RSEN5W  ISO STICK AQL ARR UP  Pictogram (Edge-Lit)
 RSEN6W  ISO STICK AQL ARR RT  Pictogram (Edge-Lit)

Certificates & Declarations

Lighting configuration

Historical range

These codes are no longer available, please order the replacement codes.
Order code Description  Monitoring type Replacement code
OW3L261 AQUALUX 2LED M3 Automatic Self Test 7331056/44
STF3L261
FREEZ-LITE 2LED M3
Automatic Self Test
7331956/44
OW3L261LS
AQUALUX 2LEDM3 LSENS IP65
Automatic Self Test
7331856/44
OW3L261V2
AQUALUX 2LED M3 220V60HZ Automatic Self Test

CTOW3L261
AQUALUX CT 2LED M3
Naveo®Pro Wired 7341056/44
CTSTF3L261
FREEZ-LITE CT 2LED M3
Naveo®Pro Wired
7341956/44
DLOW3LS60
AQUALUX 3W LED DALI M3
DALI 7339056/44
DLSTF3LS60
FREEZ LITE 3W LED DALI M3
DALI 7339956/44
OW1L261LTC
AQUALUX 2XLED 230V LTC IP65
EMEX Test 7000056/44
OW1L261HF AQUALUX 2XLED SIGN 230VHF   7000056/44
