Detailed information for: UPS PowerValue 11RT G2 10 kVA

This page contains technical data sheet, documents library and links to offering related to this product. If you require any other information, please contact us using form located at the bottom of the page.

Print...
Print to Pdf...
Data Sheet
Downloads

UPS PowerValue 11RT G2 10 kVA

General Information

  • Extended Product Type:
    UPS PowerValue 11RT G2 10 kVA
  • Product ID:
    4NWP100151R0001
  • EAN:
    7640169261831
  • Catalog Description:
    UPS PowerValue 11 RT G2 10 kVA
  • Long Description:
    VFI online double conversion;10000W;0min(long backup);RS232;USB;COM slot

Categories

  • UPS PowerValue 11RT G2 10 kVA - image 0
  • UPS PowerValue 11RT G2 10 kVA - image 1

Circular Value

  • Conflict Minerals Reporting Template (CMRT):
    9AKK108467A5658
  • RoHS Information:
    4NWD003868

Technical

  • Input Voltage (Uin):
    208 V
    220 V
    230 V
    240 V
  • Input Voltage Type:
    AC
  • Rated Frequency (f):
    Primary 50 Hz
    Primary 60 Hz
    Secondary 50 Hz
    Secondary 60 Hz
  • Apparent Power Output:
    10000 V·A
  • Rated Output Power:
    10000 W
  • Communication Interface:
    USB, RS-232
  • Number of Phases:
    Primary - 1
    Secondary - 1
  • Number of Outputs:
    C13 Connection 2
    Fixed Connections 1
  • Connection Type:
    Fixed Connection
  • Options Provided:
    Auto shut down function
    Potential free switch contact
    Network-management

Environmental

Dimensions

  • Product Net Width:
    438 mm
  • Product Net Height:
    86.5 mm
  • Product Net Depth / Length:
    573 mm
  • Product Net Weight:
    15.5 kg

Container Information

  • Package Level 1 Units:
    1 piece
  • Package Level 1 Width:
    586 mm
  • Package Level 1 Height:
    238 mm
  • Package Level 1 Depth / Length:
    766 mm
  • Package Level 1 Gross Weight:
    18.9 kg
  • Package Level 1 EAN:
    7640169261831

Ordering

  • Minimum Order Quantity:
    1 piece
  • Customs Tariff Number:
    85044000
  • E-Number (Finland):
    8408608
  • Country of Origin:
    China (CN)

Certificates and Declarations (Document Number)

Popular Downloads

  • Data Sheet, Technical Information:
    4NWD002979_EN
  • Instructions and Manuals:
    4NWD003231
  • Conflict Minerals Reporting Template (CMRT):
    9AKK108467A5658

Classifications

  • ETIM 7:
    EC000382 - UPS
  • ETIM 8:
    EC000382 - UPS
  • WEEE Category:
    4. Large Equipment (Any External Dimension More Than 50 cm)
  • WEEE B2C / B2B:
    Business To Business
  • CN8:
    85044000
  • eClass:
    V11.1 : 27040690
  • Object Classification Code:
    G
