Detailed information for: ATS-16A PowerValue

This page contains technical data sheet, documents library and links to offering related to this product. If you require any other information, please contact us using form located at the bottom of the page.

Print...
Print to Pdf...
Data Sheet
Downloads

ATS-16A PowerValue

General Information

  • Extended Product Type:
    ATS-16A PowerValue
  • Product ID:
    4NWP104041R0001
  • EAN:
    7640169262197
  • Catalog Description:
    ATS-16A PowerValue
  • Long Description:
    Automatic transfer switch for PowerValue 11RT 1-3 kVA (B/S); max 16A

Circular Value

  • Conflict Minerals Reporting Template (CMRT):
    9AKK108467A5658
  • RoHS Information:
    4NWD003871

Technical

  • Suitable For:
    UPS PowerValue 11 RT 1kVA B
    UPS PowerValue 11 RT 1kVA S
    UPS PowerValue 11 RT 2kVA B
    UPS PowerValue 11 RT 2kVA S
    UPS PowerValue 11 RT 3kVA B
    UPS PowerValue 11 RT 3kVA S
  • Suitable for Product Class:
    Single-Phase UPS
  • Accessory Type:
    Switch Unit

Environmental

Dimensions

  • Product Net Width:
    430 mm
  • Product Net Height:
    43 mm
  • Product Net Depth / Length:
    315 mm
  • Product Net Weight:
    4.8 kg

Container Information

  • Package Level 1 Units:
    1 piece
  • Package Level 1 Width:
    585 mm
  • Package Level 1 Height:
    184 mm
  • Package Level 1 Depth / Length:
    425 mm
  • Package Level 1 Gross Weight:
    8.0 kg
  • Package Level 1 EAN:
    7640169262197

Ordering

  • Minimum Order Quantity:
    1 piece
  • Customs Tariff Number:
    85369080
  • Country of Origin:
    China (CN)

Certificates and Declarations (Document Number)

Popular Downloads

  • Data Sheet, Technical Information:
    4NWD003885_EN
  • Instructions and Manuals:
    4NWD003885_EN
  • Conflict Minerals Reporting Template (CMRT):
    9AKK108467A5658

Classifications

  • ETIM 7:
    EC002850 - Accessories for UPS
  • ETIM 8:
    EC002850 - Accessories/spare parts for UPS
  • WEEE Category:
    5. Small Equipment (No External Dimension More Than 50 cm)
  • WEEE B2C / B2B:
    Business To Business
  • CN8:
    85049000
  • eClass:
    V11.1 : 27040692
  • Object Classification Code:
    A
