TVOC-2-E6-S

General Information

  • Extended Product Type:
    TVOC-2-E6-S
  • Product ID:
    1SFA664002R6001
  • EAN:
    7320500558409
  • Catalog Description:
    TVOC-2-E6-S Extension
  • Long Description:
    The extension module TVOC-2-E6-S can be assembled on the TVOC-2 main unit increase the number of detector inputs. The detectors of E6-S are supervised. There are 10 detector inputs per extension module E6-S and up to 2 extension modules can be added to the main unit, creating 30 detector inputs in total, whereof 20 can be supervised.

Categories

  • TVOC-2-E6-S - image 0

Circular Value

Environmental

  • Ambient Air Temperature:
    Operation -25 ... +55 °C
    Storage -25 ... +55 °C
  • Environmental Information:
    1SFC170003D0201
  • REACH Declaration:
    2AGS2022-006202
  • RoHS Information:
    2AGS2022-006277-RoHS
  • RoHS Status:
    Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Ordering

  • E-Number (Norway):
    4116452
  • EAN:
    7320500558409
  • Minimum Order Quantity:
    1 piece
  • Customs Tariff Number:
    85389099

Dimensions

  • Product Net Width:
    230 mm
  • Product Net Height:
    50 mm
  • Product Net Depth / Length:
    25 mm
  • Product Net Weight:
    0.14 kg

Container Information

  • Package Level 1 Units:
    box 1 piece
  • Package Level 1 Width:
    85 mm
  • Package Level 1 Height:
    55 mm
  • Package Level 1 Depth / Length:
    275 mm
  • Package Level 1 Gross Weight:
    0.226 kg
  • Package Level 1 EAN:
    7320500558409

Additional Information

  • Additional Information:
    ARC MONITOR TVOC-2 EXTENSION SUPERVISED
  • Mounting Type:
    Mounted on main unit
  • Number of Auxiliary Contacts CO (SPDT):
    0
  • Number of Auxiliary Contacts NC:
    0
  • Number of Auxiliary Contacts NO:
    0
  • Power Loss:
    1 W
  • Product Main Type:
    TVOC-2
  • Product Name:
    Extension
  • RoHS Date:
    1009 1
  • Suitable For:
    TVOC-2
  • Suitable for Product Class:
    Arc Monitor

Certificates and Declarations

Classifications

  • ETIM 7:
    EC002911 - Arc detection system
  • ETIM 8:
    EC002911 - Arc detection system
  • ETIM 9:
    EC002024 - Accessories/spare parts for command devices
  • Object Classification Code:
    B
  • UNSPSC:
    39122331
  • WEEE Category:
    5. Small Equipment (No External Dimension More Than 50 cm)
  • eClass:
    V11.0 : 27142214
