Non-invasive temperature sensor
NINVA TSP341-N



A new era of temperature measurement using non-invasive sensors.

Introducing the innovative non-invasive temperature sensor – A simpler and safer way of measuring your process temperature without the need to shut down, drill a hole or install a thermowell. With its innovative double sensor architecture and specially developed calculation algorithm, it greatly enhances your safety and reduces your installation costs without sacrificing the quality of your measurement.

My Measurement Assistant
Performance Predictor



LEAFLET
Non-invasive sensor

A new era of temperature measurement
BROCHURE
Temperature measurement

Precise and flexible for efficient processes
WHITE PAPER
NINVA TSP341-N

High-precision non-invasive temperature measurement
WEBSITE
TTF300

Field-mount temperature transmitter



My Measurement Assistant – Predict success when switching sensors
Do you really need a thermowell? Wellhead temperature monitoring
Watch our latest TechTalks recording: A simpler and safer approach to temperature measurement
Click here to watch
A new era of temperature measurement in the chemical industry
Do you really need a thermowell? Temperature sensing of industrial liquids
Click here to watch
The non-invasive temperature sensor
4 ways the non-invasive temperature sensor makes measurement easy



Overview
Data
Download
Service
Awards

Overview

The NINVA TSP341-N non-invasive temperature sensor includes a transmitter based on TTH300. Integrated new algorithms enable the high precise temperature calculation. Output via 4 to 20 mA and HART protocol. Accuracy and response time are in the range of temperature measurements with thermowell. Learn more by reading the white paper.

The temperature sensor has global approvals for explosion protection up to zone 0. The non-invasive temperature sensor belongs to ABB's product family SensyTemp TSP. It is listed in the related type examination certificates for explosion protection as SensyTemp TSP341-N.

Don't wait for the next shutdown to get your temperature measurement. Contact us today to see if the non-invasive temperature sensor can meet your requirements. Our sales team have evaluation algorithms to tell you whether this sensor could help get the performance you need, faster, safer and without having to stop your process.

Data

  • Robust connection heads
    – AGL: Aluminum, with screw-on cover
    – AGLD: Aluminum, with screw-on cover and LCD indicator type AS
    – AGS: Stainless steel, with screw-on cover
    – AGSD: Stainless steel, with screw-on cover and LCD indicator type AS
  • Transmitter in connection head
    – Based on TTH300, with integrated algorithms for non-invasive temperature measurement considering environment conditions
    – 4 to 20 mA, HART 7
    – Electrical isolation
    – Sensor monitoring and self-monitoring (NE 89, NE 107)
  • Measuring range -40 to 400 °C
  • Global approvals for explosion protection up to zone 0, intrinsic safety and flameproof enclosure
  • Consideration of the NAMUR recommendation NE 24

Download

Loading documents

Service

ABB offer a full range of services to support you and your processes, including:

Explore our comprehensive range of services at Measurement & Analytics service

German Innovation Award '19 in GOLD

ABBs innovative, non-invasive temperature sensor was awarded by the German Design Council for the German Innovation Award in GOLD in the category "Excellence in Business to Business - Electronic Technologies".


Read more about our winner and the German Innovation Award here or in our press release.



HERMES AWARD Nominee 2019

The non-invasive temperature sensor is one of the top 3 HERMES AWARD innovations 2019.

Since 2004 the HERMES AWARD, the most important international industry award, is presented by Deutsche Messe to companies that have been able to assert themselves against their competitors thanks to a particular degree of technological innovation. Only industrially proven technology solutions are considered. In addition, socio-economic aspects are included in the evaluation of the independent jury.
