Ethernet-APL at the field level in hazardous and non-hazardous areas

Ethernet-APL for flow measurement

Discover cutting-edge networking technology with ABB's pioneering Ethernet-APL integrated measurement solutions

Ethernet has long been recognized for its potential to boost productivity, efficiency, and flexibility in process industry factories. However, before the era of the Advanced Physical Layer (APL), deploying Ethernet at the field instruments level in hazardous locations was impossible due to stringent safety standards.

Now, you can take your plant operations to the next level with ABB Ethernet-APL flowmeters.

The advanced SwirlMaster and VortexMaster models we offer are built to adhere to the highest safety requirements, including those for chemical, hydrogen, and oil & gas installations.
Ethernet-APL
Leaflet
SwirlMaster and VortexMaster with Ethernet-APL | Download the brochure to learn more
 abb's-pioneering-ethernet-apl-integrated-measurement-solutions

Key benefits of Ethernet-APL

Power and data transfer at the speed of light

Key process information readily available through a two-cable communication solution.
Ease of integration and use


Smooth integration of Ethernet-APL with the current Ethernet setups, allowing for deployment without major system overhauls.
Seamless remote monitoring capabilities

Leveraging the IP protocol for unparalleled remote monitoring capabilities and instant access to crucial process data.
Real-time and data-driven maintenance

Valuable insights on the performance and health of instruments, allowing for proactive maintenance and troubleshooting.

Discover and leverage ABB's first Ethernet-APL devices to measure the flow of liquids, gases and steam

Swirl flowmeters
Downloads available on product page
Vortex flowmeters
Downloads available on product page

Embrace the power of standard Ethernet in our other measurement solutions

CoriolisMaster FCD450 – Smaller Meter Sizes with Ethernet
Downloads available on product page
CoriolisMaster FCB430 and FCB450 with Ethernet
Downloads available on product page
CoriolisMaster FCH430 and FCH450 with Ethernet
Downloads available on product page
Now available in the Americas
ProcessMaster FEP630 with Ethernet
Downloads available on product page
Now available in the Americas
HygienicMaster FEH630 with Ethernet
Downloads available on product page

Ethernet-APL provides online access to all meter and application information. Another positive option is the ability to provide online support or firmware upgrade capabilities even in the most remote regions of the world.

Let's work together to bring your chemical, hydrogen or oil and gas plant into a bright future!

The business case for digitization is undisputed

Power over Ethernet

Omits the need for a separate DC power infrastructure - power and comms via the same cable

Secure web server

Allows easy ability to check readings and trouble-shoot problems with no need for tools and drivers to set up the meter

Integrated device verification

Creates a convenient way to check meters via the web and print comprehensive reports

High performance Ethernet switch

Provides redundant connections to the PLC operator panel and also daisy-chain wiring to save installation costs

Leading industrial Ethernet protocols

Enables use of any industrial protocol - from simple Modbus TCP, to high performance EtherNet/IP

EthernetIP, Modbus TCP, Web Browser and Profinet

More data from the device for better decision-making and the best level of process efficiency

Dynamic QR Code

Transfers device health and verification results quickly and remotely to mobile devices

Ready for TSN and secure industrial protocols

Prepares operations for the future, as network convergence will soon be brought down to meters with multiple protocols

Start upgrade 4...20 mA installations

Combines 4...20 mA output and future-proof digital communication at up to 100 Mbit/s for traditional Ethernet and 10/Mbit/s for Ethernet-APL.



What does this mean for you?

Simplicity

PoE uses standard Ethernet cables like a typical network. Special tools, additional electrical outlets, different cables, and expensive hardware are no longer required.

Flexibility

Remote and centralized power, along with scalable solutions, allow flexibility in adapting to the changing needs of an application.

Cost savings

PoE uses off-the-shelf components. Part of an installation from the start or as a later upgrade, PoE needs just one cable, cutting installation efforts in half.

Increased reliability

Centralized power enables back-up solutions with uninterruptible power supply systems. Devices can be remotely powered down during periods of low usage or for security or safety reasons.
